FT-40 (65053)-261

The fire truck FT-40 (65053)-261 is intended for delivering the fire-prevention crew and facilities to place of the fire and serves for extinguishing the fire with water and air-mechanical foam. It is used as an independent combat unit at extinguishing fire, liquidation damage and consequences of natural disasters.

Consultation

Technical characteristics

Additional information

Base chassis	КрАЗ 65053
Wheel formula	6х4
Power (max), kW (hp)	243 (330)
Speed (max), with full load, km / h	90
The number of places for combat crew, people	1 +6
Productivity, l / s, not less	0,04 (40)
Pump head, m	100
Duration of filling the pump at the highest geometric suction height, s, not more	40
Type of water filling system	electric vacuum pump
Water supply, m3 (l)	8 (8000)
Frother, not less	0,5 (500)
Fire monitors	Multimode, stationary, with remote control
Water jet delivery range, m	50
Range of supply of a foamy direct stream, m	45
sprayed water torch 30˚	30
Maximum geometric suction lift, m	7,5
Overall dimensions (length: width: height), mm	10850:2500:3650
Mass of the car with full load, kg	22000

Base chassis

КрАЗ 65053

Wheel formula

6х4

Power (max), kW (hp)

243 (330)

Speed (max), with full load, km / h

The number of places for combat crew, people

1 +6

Productivity, l / s, not less

0,04 (40)

Pump head, m

100

Duration of filling the pump at the highest geometric suction height, s, not more

Type of water filling system

electric vacuum pump

Water supply, m3 (l)

8 (8000)

Frother, not less

0,5 (500)

Fire monitors

Multimode, stationary, with remote control

Water jet delivery range, m

Range of supply of a foamy direct stream, m

sprayed water torch 30˚

Maximum geometric suction lift, m

7,5

Overall dimensions (length: width: height), mm

10850:2500:3650

Mass of the car with full load, kg

22000

ZIL PMZ 53A fire truckThe history of the PMZ-53A began with the production of a series of PMZ-53 tank trucks with a metal body and a cabin. The car was equipped with a pump PN-ZOK, tank capacity - 1950 l. On the back wall of the tank truck of the first issues was mounted mounting for the removable sleeve coil RK-3, which was wound seven rubberized sleeves. The model PMZ-53A, manufactured since 1960, the rear detachable sleeve coil was not installed, tanker produced on the chassis ZIL-164A After further modernization (increasing the tank capacity for water up to 2100 l and foaming agent up to 150 l), which resulted in an increase in the total weight of the car to 8270 kg, the designers managed to reduce the overall length of the tanker to 6930 mm. The machine was assigned the PMZ-53A index. Release of tank trucks PMZ-53A was discontinued in 1965.Details →
