Tank truck ACPT-7,5The tank truck ACPT-7,5 is intended for transportation and short-term storage of drinking water, and also maintenance in capacity of plus temperature of water during all term of storage.Details →
Technical characteristics
Additional information
| Base chassis | KrAZ-6511 |
|---|---|
| Wheel formula | 6х6.2 |
| Maximum engine power, kWt (h.p.) | 276 (375) |
| Speed (max), with full load, km / h | 90 |
| The number of places for combat crew, people | 1+5 |
| Water supply, m3 (l) | 8 (8000) |
| Pump | FPN 10-3000 JOHSTADT, FPN 10-3000 Pozchmachina, FPN 10-3000 Rosenbauer |
| Type of water filling system | Automatic built-in pump |
| Pump capacity, l/min (l/sec) | 3000 (50) |
| Pump head, m | 170 (1,7 МPа / 17 bar) |
Additional information
In addition to the equipment that has already become standard for fire trucks of our production, such as a winch with a traction force of 9 tons, a thermal imager, group and individual lights, walkie-talkies, etc., this tank truck has many novelties. (For more details, see the description of AC-4-60 (530927) -515M). First of all, you should pay attention to such updates as:
- mast in the middle of the body with 24V and 220V lights;
- smoke extractor with sleeve for high multiplicity foam;
- inverter 24V / 220V;
- hydraulic tool for unclamping and cutting with autonomous power supply;
- floating motor pump and suction net, which take water from the surface of the water;
- a new mechanism for removing the three-knee ladder.
For convenience of extinguishing of ecosystems the tank truck has a gun barrel on a bumper with remote control.
The protective grilles of lanterns, lights, stroboscopes and reflectors have also been updated - now they are made of stainless steel.
See more details in the video review.
Пожежна надбудова аналогічна АЦ-8-50 (63022)-530М
