АЦ – 40 (130) – 63Б

Fire-Extinguishing Tanker AЦ-40(130) model 63Б is intended for delivering the fire-fighting crew and fire-fighting facilities to the site of fire and is designed for smothering a fire with water or air-mechanical foam.

Technical characteristics

Additional information

Base chassis	ЗИЛ-431412/4x2 (или аналог)
Engine	carburetor
Power (max), kW (hp)	110(150)
Speed (max), with full load, km / h	90
The number of places for combat crew, people	1 +6
Water supply, m3 (l)	2,36 (2360)
Frother, not less	0,17 (170)
Length of pressure hoses, m	348
Pump	single-stage centrifugal НЦП-40/100-Р-Р
Pump capacity, l/min (l/sec)	40
Pump head, m	100
Number of hand barrels	6
Overall dimensions (length: width: height), mm	7680:2500:2780
Mass of the car with full load, kg	9600
Type of water filling system	a vacuum jet pump

Order Consultation
