Airfield Fire Extinguishing Engine АА – 13/60 (6560) – 270.03 is intended for smothering the fires in aircrafts and helicopters of civil aviation and of the Air-Force, accompanied by burning of aviation fuel, constructional and finishing materials used in aircraft manufacture and also for extinguishing the fire in the other objects at the aerodromes and airports. АА – 13/60 (6560) – 270.03 -Base chassis КАМАЗ 6560 (8х8), crew 1+5, water tank capacity, m3 (l), at least 12 (12000), foam tank capacity, m3 (l), at least 0,8 (800).
| Wheel formula | 8х8 |
|---|---|
| Base chassis | КАМАЗ – 6560 |
| Power (max), kW (hp) | 294 (400) |
| Speed (max), with full load, km / h | 90 |
| The number of places for combat crew, people | 1+5 |
| Pump | centrifugal |
| Pump capacity, l/min (l/sec) | 0,06(60) |
| Pump head, m | 100 |
| Maximum geometric suction lift, m | 7,5 |
| Water supply, m3 (l) | 12(12000) |
| Frother, not less | 0,8 (800) |
| Fire monitors | ЛСД-С60У, ЛСД-С20У with remote control |
| water, m | 65, 50 |
| sprayed water torch 30˚ | 44, 30 |
| foam, m | 60, 35 |
| flow rate, l / min (l / s) | 60, 20 |
| Length of pressure hoses, m | 388 |
| Number of foam generators pcs. | ГПС-600, 8pcs. |
| foam width in one pass, m, not less | 8 |
| mass of CO2 charge, kg | 56 |
| Number of sleeves, pcs. / Sleeve Length, m | 1 / 20 |
| trunk of a punch | 1 |
| Trumpet | 1 |
| Overall dimensions (length: width: height), mm | 13200:2550:3700 |
| Mass of the car with full load, kg | 38800 |
