АЦ-60 (53229) – 263 is intended for delivery of rge fire-fighting crew an facilities to the site of fire and serves for vextinguishing fire by water or air-mechanical foam. It is used at extinguishing fires, emergency rescue situations.
| Base chassis | КамАЗ-53229 |
|---|---|
| Wheel formula | 6х4 |
| Engine | 740.31 diesel turbine |
| Power (max), kW (hp) | 176 (240) |
| Speed (max), with full load, km / h | 80 |
| The number of places for combat crew, people | 1 +6 |
| Pump | ПН-60Б |
| Pump capacity, l/min (l/sec) | 60 |
| Pump head, m | 100 |
| Type of water filling system | electric vacuum system |
| Maximum geometric suction lift, m | 7,5 |
| diameter of the suction inlet pipe, mm | 125 |
| diameter / number of pressure nozzles, mm / pcs. | 80/2 |
| Fire monitors | ЛС-С40 (stationary) |
| water, m | 60 |
| foam, m | 40 |
| Water supply, m3 (l) | 8 (8000) |
| Frother, not less | 0,58 (580) |
| Overall dimensions (length: width: height), mm | 9300:2500:3450 |
| Mass of the car with full load, kg | 22000 |
