Fire-fighting tanker АЦ-40(5336)-245 is intended for fire protection of cities and villages, industrial installations and serves for:
– delivery of fire-fighting crew and facilities to the site of fire and providing first medicla aid;
– delivery of water to the site of fire from open basin or hydrant, initial tank through hand barrels and portable monitor;
– delivery of air-mechanical foam to the site of fire using foam agent from foam tank or taking foam agent from other capacity through hand foamgenerator;
-water pumping at large distance from the site of fire;- placement of head hose main lines;
– possible operation of fire-fighting tanker as air-foam extinguishing tanker at using tank for foam agent.
| Base chassis | МАЗ-533603-241 / 4х2 |
|---|---|
| Engine | diesel turbocharged |
| Power (max), kW (hp) | 184 (250) |
| Speed (max), with full load, km / h | 100 |
| The number of places for combat crew, people | 1+5 |
| Water supply, m3 (l) | 4,6 (4600) |
| Frother, not less | 0,4 (400) |
| Type of water filling system | Autonomous vacuum pump, slide type with electric drive and automatic shutdown after filling |
| Length of pressure hoses, m | 328 |
| Pump | centrifugal НЦП – 40/100-Р-Р |
| Pump capacity, l/min (l/sec) | 0,04 (40) |
| Pump head, m | 100 |
| nominal rotational speed, RPM | 2700 |
| Maximum geometric suction lift, m | 7,5 |
| Duration of filling the pump at the highest geometric suction height, s, not more | 40 |
| Overall dimensions (length: width: height), mm | 8300: 2500: 3260 |
| Mass of the car with full load, kg | 18000 |
