ПН 60 Б

Description

Fire pump  ПН 60 Б is intended for feeding of  fire-extinguishing liquids, range of temperature is  till 303K (+30˚C) , hydrogen index (pH) is  from 7 till 10, density is till 1010 kg/m3 and mass concentration of hard particle is till 5%, its max. size is 3 mm.

Specifications

Pump

Centrifugal, single-stage, console

Pump capacity, l/min (l/sec)

60

Pump head, m

100

Efficiency,%

58

Cavitation / critical / stock, m, not more

3,5

Speed, rpm

2600

Power consumption, kW (hp), not more

101 (138)

Limit the number of revolutions

2650

Extreme pressure at the exit from the pump

40

Maximum head at the pump inlet, m

110

Overall dimensions (length: width: height), mm

980:820:900

Curb weight, kg, not more

250
