Mobile oil and gas pumping industrial installation UNPN-160х40

Description

Specifications

Mass of the car with full load, kg

25 000

Overall dimensions (length: width: height), mm

11000/11300:2600:3550

Pump

ЦНС 38-132 centrifugal, multistage

Pump capacity, l/min (l/sec)

38 (10,5)

Base chassis

КрАЗ-63221-05

The number of places for combat crew, people

2

Spare wheel

there is

Engine

ЯМЗ-53603-30 type in-line, 6-cylinder, diesel with turbocharger

Environmental standard

Euro-5

Power (max), kW (hp)

246,6 (330)

transmission

9JS150TA-B, mechanical type, 2-band, 9-speed – mechanical control, remote

number of gears (forward + backward)

9+1

Clutch

1-disk, dry, with PGU

Steering gear

mechanical, with hydraulic booster

Speed (max), with full load, km / h

75

Fuel tank capacity, l, not less

250 х 2

Turning radius, overall, m

14

Additional Information

Mobile oil and gas pumping industrial installation УНПН-160х40 is designed for injection of various liquid media during cementing wells during drilling and overhaul, as well as during other washing and prodding operations in oil and gas wells. The unit is designed to work in temperate and cold macro-climatic zones.
