АППД - 2 (3310) - 274 – ПОЖМАШИНА

АППД - 2 (3310) - 274

Description

Fire first aid car АППД-2(3310) 274 is intended for suppression fire, liquidations of consequences of extraordinary situations and serves for delivering the fire-fighting crew, fire-fighting facilities and emergency-rescue equipment to the place of fire; for serving water and air-mechanical foam to the place of fire, for realization of wrecking.

Specifications

Base chassis

ГАЗ – 3310/4х2

Engine

diesel

Power (max), kW (hp)

86,2(117,2)

Speed (max), with full load, km / h

95

The number of places for combat crew, people

1+5

Water supply, m3 (l)

1(1000)

Frother, not less

0,05(50)

Type of water filling system

jet pump vacuum (slide type with electric drive and manual control)

Length of pressure hoses, m

100

Pump

МНВП-90/300 or equivalent

Pump capacity, l/min (l/sec)

1,5 (0,0015)

Pump head, m

300

Maximum geometric suction lift, m

7,5±0.2

Number of hand barrels

2

Overall dimensions (length: width: height), mm

6950:2350:2900

Mass of the car with full load, kg

7400
