АЦ-4,5-70 (TGM 12.250)-464 – ПОЖМАШИНА

АЦ-4,5-70 (TGM 12.250)-464

Description

Fire-extinguishing tanker is intended for: -Delivering fire-fighting crew, fire-extinguishing facilities, fire-technical and emergency-rescue equipment to the place of fire, in cities and in rural areas to save people and extinguish fire; -Extinguishing of fire by water from cistern, open reservoir, plumbing network or extraneous capacity water through: monitor and (or) hand barrels; -Extinguishing of fire by air-mechanical foam with the use of foam generator from foam tank or extraneous capacity through: monitor, and (or) hand foam generator

Specifications

Base chassis

MAN TGM 12.250 4х2 BL

Power (max), kW (hp)

184 (250)

Speed (max), with full load, km / h

110

The number of places for combat crew, people

1 +6

Water supply, m3 (l)

4,0 (4000)

Frother, not less

0,5 (500)

Type of water filling system

Automatic built-in pump

Pump

centrifugal

Pump capacity, l/min (l/sec)

4200 (70)

Pump head, m

100

Maximum geometric suction lift, m

7,5

Duration of filling the pump at the highest geometric suction height, s, not more

40

Overall dimensions (length: width: height), mm

7200: 2450: 3270

Mass of the car with full load, kg

12000
