АЦ - 40 (131) - 137A

Fire-Extinguishing Tanker AU-40(131) model 137A is intended for delivering the fire- fighting crew and fire-fighting facilities to the site of fire and is designed for smothering a fire with water or air-mechanical foam.

Specifications

Base chassis

ЗИЛ 131/6×6

Engine

carburetor

Power (max), kW (hp)

110(150)

Speed (max), with full load, km / h

80

The number of places for combat crew, people

1 +6

Water supply, m3 (l)

2,73 (2730)

Frother, not less

0,17 (170)

Length of pressure hoses, m

408

Fire monitors

СЛК-П20

water, m

50

foam, m

35

Pump

single-stage centrifugal НЦП-40/100-Р-Р

Pump capacity, l/min (l/sec)

40

Pump head, m

100

Number of hand barrels

6

Overall dimensions (length: width: height), mm

7640:2500:2950

Mass of the car with full load, kg

11100
