Legend in a new guise

TF-2,0-40 (HD65)-477

Description

The fire-extinguishing tanker fire AЦ-2,0-40 (HD65)-477 is intended for delivery the fire fighting crew, fire extinguishing equipment, fire-technical equipment (PTV) to the place of fireand serves for extinguishing fires with water and air-mechanical foam.

Specifications

Base chassis

Hyundai НD65/4×2

Engine

diesel

Power (max), kW (hp)

103(140)

Speed (max), with full load, km / h

100

The number of places for combat crew, people

1 +6

Water supply, m3 (l)

2,0 (2000)

Frother, not less

0,12 (120)

Type of water filling system

vacuum with electric drive

Length of pressure hoses, m

408

Pump

centrifugal НЦП-40/100-Р-Р

Pump capacity, l/min (l/sec)

40

Pump head, m

100

Maximum geometric suction lift, m

7,5

Number of hand barrels

2

Overall dimensions (length: width: height), mm

6535:2135:2725

Mass of the car with full load, kg

6500
